Fuzzy logic

The Big Search Opportunity

Henrik Gabs LiliendahlLeave a comment

The other day Bloomberg Businessweek had an article telling that Facebook Delves Deeper Into Search.

I have always been advocating for having better search functionality in order to get more business value from your data. That certainly also applies to big data.

In a recent post called Big Reference Data Musings here on the blog, the challenge of utilizing large external data sources for getting better master data quality was discussed. In a comment Greg Leman pointed out, that there often isn’t a single source of the truth, as you for example could expect from say a huge reference data source as the Dun & Bradstreet WorldBase holding information about business entities from all over the world.

Indeed our search capabilities optimally must span several sources. In the business directory search realm you may include several sources at a time like supplementing the D&B  WorldBase with for example EuroContactPool, if you do business in Europe, or the source called Wiki-Data (under rename to AvoxData) if you are in financial services and wants to utilize the new Legal Entity Identifier (LEI) for counterparty uniqueness in conjunction with other more complete sources.

As examined in Search and if you are lucky you will find combining search on external reference data sources and internal master data sources is a big opportunity too. In doing that you, as described the follow up piece named Wildcard Search versus Fuzzy Search, must get the search technology right.

I see in the Bloomberg article that Facebook don’t intend to completely reinvent the wheel for searching big data, as they have hired a Google veteran, the Danish computer scientist Lars Rasmussen, for the job.

Bookmark and Share

Wildcard Search versus Fuzzy Search

Henrik Gabs LiliendahlLeave a comment

My last post about search functionality in Master Data Management (MDM) solutions was called Search and if you are lucky you will find.

In the comments the use of wildcards versus fuzzy search was touched.

The problem with wildcards

I have a company called “Liliendahl Limited” as this is the spelling of the name as it is registered with the Companies House for England and Wales.

But say someone is searching using one of the following strings:

  • “Liliendahl Ltd”,
  • “Liliendal Limited” or
  • “Liljendahl Limited”

Search functionality should in these situations return with the hit “Liliendahl Limited”.

Using wildcard characters could, depending on the specific syntax, produce a hit in all combinations of the spelling with a string like this: “lil?enda*l l*”.

The problem is however that most users don’t have the time, patience and skills to construct these search strings with wildcard characters. And maybe the registered name was something slightly else not meeting the wildcard characters used.

Matching algorithms

Tools for batch matching of name strings have been around for many years. When doing a batch match you can’t practically use wildcard characters. Instead matching algorithms typically rely of one, or in best case a combination, of these techniques:

The same techniques can be used for interactive search thus reaching a hit in one fast search.

Fuzzy search

I have worked with the Omkron FACT algorithm for batch matching. This algorithm has morphed into being implemented as a fuzzy search algorithm as well.

One area of use for this is when webshop users are searching for a product or service within your online shop. This feature is, along with other eCommerce capabilities, branded as FACT-Finder.

The fuzzy search capabilities are also used in a tool I’m involved with called iDQ. Here external reference data sources, in combination with internal master data sources, are searched in an error tolerant way, thus making data available for the user despite heaps of spelling possibilities.

Bookmark and Share

The Present Birthday

Henrik Gabs Liliendahl4 Comments

Today (or maybe yesterday) Steve Jones of Capgemeni wrote a blog post called Same name, same birth date – how likely is it? The post examines the likelihood of that two records with the same name and birthday is representing same real world individual. The chance that a match is a false positive is of course mainly depending on the frequency of the name.

Another angle in this context I have observed over and over again is the chance of a false negative if the name and other data are the same, but the birthday is different. In this case you may miss matching two records that are actually reflecting the same real world individual.

One should think that a datum like a birthday usually should be pretty accurate. My practical experience is that it in many cases isn’t.

Some examples:

Running against the time

Every fourth year when we have Olympic Games there is always controversies about if a tiny female athlete really is as old as said.

I have noticed the same phenomenon when I had the chance to match data about contesters from several years of subscription data at a large city marathon in order to identify “returning customers”.

I’m always looking for false positives in data matching and was really surprised when I found several examples of same name and contact data but a birthday been raised one year for each appearance at the marathon.

That’s not my birthday, this is my birthday

Swedish driving license numbers includes the birthday of the holder as the driving license number is the same as the all-purpose national ID that starts with the birthday.

In a database with both a birthday field and a driving license number field there were heaps of records with mismatch between those two fields.

This wasn’t usually discovered because this rule only applies to Swedish driving license numbers and the database also had registrations for a lot of other nationalities.

When investigating the root cause of this there were as usual not a single explanation and the problem could be both that the birthday belonged to someone else and the driving license belonged to someone else.

Using both fields cut down the number of false negatives here.

Today’s date format is?

In the United States and a few other countries it’s custom to use the month-day-year format when typing a date. In most other places we have the correct sequence of either day-month-year or year-month-day.  Once I matched data concerning foreign seamen working on ships in the Danish merchant fleet. When tuning the match process I found great numbers of good matches when twisting the date formats for birthdays, as the same seaman was registered on different ships with different captains and at different ports around the world.

When adding the fact that many birthdays was typed as 1st January of the known year of birth or 1st day in the known month of birth a lot of false positives was saved.

The question about occupation in the merchant fleet was actually a political hot potato at that time and until then the parliament had discussed the matter based on wrong statistics.

PS

I have used birthday synonymously with “date of birth” which of course is a (meta) data quality problem.

Bookmark and Share

The Art in Data Matching

Henrik Gabs Liliendahl12 Comments

I’ve just investigated a suspicious customer data match:

A Company on Kunstlaan no 99 in Brussel

was matched with high confidence with:

The Company on Avenue des Arts no 99 in Bruxelles

At first glance it perhaps didn’t look as a confident match, but I guess the computer is right.

The diverse facts are:

  • Brussels is the Belgian capital
  • Belgium has two languages: French and Flemish (a variant of Dutch)
  • Some parts of the country is French, some parts is Flemish and the capital is both
  • Brussels is Bruxelles in French and Brussel in Flemish
  • Kunst is Flemish meaning Art (as in Dutch, German and Scandinavian too)
  • Laan is Flemish meaning Avenue (same origin as Lane I guess)
  • Avenue des Arts is French meaning Avenue of Art (French is easy)

Technically the computer in this case did as follows:

  • Compared the names like “A Company” and “The Company” and found a close edit distance between the two names.
  • Remembered from some earlier occasions that “Kunstlaan” and “Avenue des Arts” was accepted as a match.
  • Remembered from numerous earlier occasions that “Brussel”(or “Brüssel) and “Bruxelles” was accepted as a match.

It may also have been told beforehand that “Kunstlaan” and “Avenue des Art” are two names of the same street in some Belgian address reference data which I guess is a must when doing heavy data matching on the Belgian market.

In this case it was a global match environment not equipped with worldwide address reference data, so luckily the probabilistic learning element in the computer program saved the day.

Bookmark and Share

Lots of Product Names

Henrik Gabs Liliendahl2 Comments

In master data management the two most prominent domains are:

  • Parties and
  • Products

In the quest for finding representations of parties actually being the same real world party and finding representations of products actually being the same real world product we typically execute fuzzy data matching of:

  • Party names as person names and company names
  • Product descriptions

However I have often seen party names being an integral part of matching products.

Some examples:

Manufacturer Names:

A product is most often being regarded as distinct not only based on the description but also based on the manufacturer. So besides being sharp on matching product descriptions for light bulbs you must also consider if for example the following manufacturer company names are the same or not:

  • Koninklijke Philips Electronics N.V.
  • Phillips
  • Philips Electronic

Author Names:

A book is a product. The title of the book is the description. But also the author’s person name counts. So how do we collect the entire works made by the author:

  • Hans Christian Andersen
  • Andersen, Hans Christian
  • H. C. Andersen

as all three representations are superb bad data?

Bear Names:

A certain kind of teddy bears has a product description like “Plush magenta teddy bear”. But each bear may have a pet name like “Lots-O’-Huggin’ Bear” or just short “Lotso” as seen in the film “Toy Story 3”. And seriously: In real business I have worked with building a bear data model and the related data matching.

PS: For those who have seen Toy Story 3: Is that Lotso one or two real world entities?

Bookmark and Share

Matching Down Under

Henrik Gabs Liliendahl4 Comments

As a data matching geek I always love reading about how others have made the great but fearful journey into the data matching world.

This week Wayne Colless of the Australian Attorney-General’s Department kindly made a document about data matching public on the DataQualityPro site. The full title is “Improving the Integrity of Identity Data – Data Matching Better Practice Guidelines, 2009”. Link here.

As Wayne explains in a discussion in the LinkedIn Data Matching group: Australia has no national unique identifier for individuals (such as the US SSN or the number recorded on national ID cards used in many other countries) that can be used, so the matching has to involve only non-unique values such as name, address and dates of birth.

The document gives a very thorough step by step guidance into matching individual’s names, addresses and birthdays. As the document says you may either build all the logic yourself or you may buy commercial software that does the same. But anyway you have to understand what the software does in order to tune the processes and set the thresholds meaningful to you.

As Australia is a nation mainly born through immigration the challenges with adapting the ruling Anglo-Saxon naming conventions to the reality of name formats coming from all over the world is very apparent. I like that the diversity issues is given a good thought in the document.

I also like that the document addresses a subject not mentioned as often as it should be, namely the challenges with embracing historical values in settling a match as seen in this figure taken from the document:

Whether you think you already know the dos and don’ts in data matching (and I guess you never know that) I really find the document worth reading.

Bookmark and Share

The Overlooked MDM Feature

Henrik Gabs LiliendahlLeave a comment

When engaging in the social media community dealing with master data management an often seen subject is creating a list of important capabilities for the technical side of master data management. I have at some occasions commented on such posts by adding a feature I often see omitted from these lists, namely: Error tolerant search functionality. Examples from the DataFlux CoE blog here and the LinkedIn Master Data Management Interest Group here.

Error tolerant search (also called fuzzy search) technology is closely related to data matching technology. But where data matching is basically none interactive, error tolerant search is highly interactive.

Most people know error tolerant search from googling. You enter something with a typo and google prompts you back with: Did you mean…? When looking for entities in master data management hubs you certainly need something similar. Spelling of names, addresses, product descriptions and so on is not easy – not at least in a globalized world.

As in data matching error tolerant search may use lists of synonyms as the basic technology. But also the use of algorithms is common going from an oldie like the soundex phonetic algorithm over more sophisticated algorithms.

The business benefits from having error tolerant search as a capacity in your master data management solution are plenty, including:

  • Better data quality by upstream prevention against duplicate entries as explained in this post.
  • More efficiency by bringing down the time users spends on searching for information about entities in the master data hub.
  • Higher employee satisfaction by eliminating a lot of frustration else coming from not finding what you know must be inside the hub already.

Error tolerant search has been one of the core features in the master data management implementations where I have been involved. What about you?

Bookmark and Share

Testing a Data Matching Tool

Henrik Gabs LiliendahlLeave a comment

Many technical magazines have tests of a range of different similar products like in the IT world comparing a range of CPU’s or a selection of word processors. The tests are comparing measurable things as speed, ability to actually perform a certain task and an important thing as the price.

With enterprise software as data quality tools we only have analyst reports evaluating the tools on far less measurable factors often given a result very equivalent to stating the market strength. The analysts haven’t compared the actual speed; they have not tested the ability to do a certain task nor taken the price into consideration.

A core feature in most data quality tools is data matching. This is the discipline where data quality tools are able to do something considerable better than if you use more common technology as database managers and spreadsheets, like told in the post about deduplicating with a spreadsheet.

In the LinkedIn data matching group we have on several occasions touched the subject of doing a once and for all benchmark of all data quality tools in the world.

My guess is that this is not going to happen. So, if you want to evaluate data quality tools and data matching is the prominent issue and you don’t just want a beauty contest, then you have to do as the queen in the fairy tale about The Princess and the Pea: Make a test.

Some important differentiators in data matching effectiveness may narrow down the scope for your particular requirements like:

  • Are you doing B2C (private names and addresses), B2B (business names and addresses) or both?
  • Do you only have domestic data or do you have international data with diversity issues?
  • Will you only go for one entity type (like customer or product) or are you going for multi-entity matching?

Making a proper test is not trivial.

Often you start with looking at the positive matches provided by the tool by counting the true positives compared to the false positives. Depending on the purposes you want to see a very low figure for false positives against true positives.

Harder, but at least as important, is looking at the negatives (the not matched ones) as explained in the post 3 out of 10.

Next two features are essential:

  • In what degree are you able to tune the match rules preferable in a user friendly way not requiring too much IT expert involvement?
  • Are you able to evaluate dubious matches in a speedy and user friendly way as shown in the post called When computer says maybe?

A data matching effort often has two phases:

  • An initial match with all current stored data maybe supported by matching with external reference data. Here speed may be important too. Often you have to balance high speed with poor results. Try it.
  • Ongoing matching assisting in data entry and keeping up with data coming from outside your jurisdiction. Here using data quality tools acting as service oriented architecture components is a great plus including reusing the rules from the initial match. Has to be tested too.

And oh yes, from my experience with plenty of data quality tool evaluation processes: Price is an issue too. Make sure to count both license costs for all the needed features and consultancy needed experienced from your tests.

Bookmark and Share

To be called Hamlet or Olaf – that is the question

Henrik Gabs LiliendahlLeave a comment

Right now my family and I are relocating from a house in a southern suburb of Copenhagen into a flat much closer to downtown. As there is a month in between where we haven’t a place of our own, we have rented a cottage (summerhouse) north of Copenhagen not far from Kronborg Castle, which is the scene of the famous Shakespeare play called Hamlet.

Therefore a data quality blog post inspired by Hamlet seems timely.

Though the feigned madness of Hamlet may be a good subject related to data quality, I will however instead take a closer data matching look at the name Hamlet.

Shakespeare’s Hamlet is inspired by an old Norse legend, but to me the name Hamlet doesn’t sound very Norse.

Nor does the same sounding name Amleth found in the immediate source being Saxo Grammaticus.

If Saxo’s source was a written source, it may have been from Irish monks in Gaelic alphabet as Amhlaoibh where Amhl=owl and aoi=ay and bh=v sounding just like the good old Norse name Olav or Olaf.

So, there is a possible track from Hamlet to Olaf.

Also today a fellow data quality blogger Graham Rhind posted a post called Robert the Carrot with the same issue. As Graham explains, we often see how data is changed through interfaces and in the end after passing through many interfaces doesn’t look at all as it was when first entered. There may be a good explanation for each transformation, but the end-to-end similarity is hard to guess when only comparing these two.

I have met that challenge in data matching often. An example will be if we have the following names living on the same address:

  • Pegy Smith
  • Peggy Smith
  • Margaret Smith

A synonym based similarity (or standardization) will find that Margaret and Peggy are duplicates.

An edit distance similarity will find that Peggy and Pegy are duplicates,

A combined similarity algorithm will find that all three names belong to a single duplicate group.

Bookmark and Share

The Sound of Soundex

Henrik Gabs LiliendahlLeave a comment

The probably oldest and most used error tolerant algorithm in searching and data matching is a phonetic algorithm called Soundex. If you are not familiar with Soundex: Wikipedia to the rescue here.

In the LinkedIn group Data Matching we seem to have an ongoing discussion about the usefulness of Soundex. Link to the discussion here – if you are not already a member: Please join, spammers are dealt with, though it is OK to brag about your data matching superiority.

To sum up the discussion on Soundex I think we at this stage may conclude:

  • Soundex is of course very poor compared to the more advanced algorithms, but it may be better than nothing (which will be exact searching and matching)
  • Soundex (or a variant of Soundex) may be used for indexing in order to select candidates to be scored with better algorithms.

Let’s say you are going to match 100 rows with names and addresses against a table with 100 million rows with names and addresses and let’s say that the real world individual behind the 100 rows is in fact represented among the 100 million, but not necessary spelled the same.

Your results may be as this:

  • If you use exact automated matching you may find 40 matching rows (40 %).
  • If you use automated matching with (a variant of) Soundex you may find 95 matching rows, but only 70 rows (70 %) are correct matches (true positives) as 25 rows (25 %) are incorrect matches (false positives).
  • If you use automated matching with (a variant of) Soundex indexing and advanced algorithm for scoring you may find 75 matching rows where 70 rows (70 %) are correct matches (true positives) and 5 rows (5 %) are incorrect matches (false positives).
  • By tuning the advanced algorithm you may find 67 matching rows where 65 rows (65 %) are correct matches (true positives) and 2 rows (2 %) are incorrect matches (false positives).

So when using Soundex you will find more matching rows but you will also find more manual work in verifying the results. Adding an advanced algorithm may reduce the manual work or eliminate manual work at the cost of some not found matches (false negatives) and the risk of a few wrong matches (false positives).

PS: I have a page about other Match Techniques including standardization, synonyms and probabilistic learning.

PPS: When googling for if the title of this blog has been used before I found this article from a fellow countryman.

Bookmark and Share
